板材打磨設備

Single Head Bridge Polishing MachineHLAP-1800橋式磨機

領跑智能制造新“石”代

Single Head Bridge Polishing MachineHLAP-1800橋式磨機

所屬品牌:

所屬類別:板材打磨設備

想了解更多相關產品信息,請聯系我們!

0594-2197723
hualongmc@163.com
我要咨詢
  • 產品說明
  • 技術參數


采購可留言電話(hua)號碼,我(wo)們會與(yu)您聯系!

Purchase please leave a message phone and email, we will contact you!




單頭橋式拋光機
HLAP-1800 是一款橋式表面拋光機,具備自動換頭功能,精度高、穩定性強,用途廣泛且效率高,是用于各種材料(如花崗巖、石英、大理石、石灰石等)的校準、啞光研磨、拋光、刷洗和盤式噴砂等工作的全能型設備。這款平板拋光機可配置成多種不同的方案,具有兩種不同的橫向移動尺寸(2220 毫米或 3200 毫米),具備自動換刀功能,還有機械式或電動式停止裝置……等等。跑道的長度可以根據您的需求以及您的工作區域進行調整。
Single Head Bridge Polishing Machine with Automatic Tool Change
HLAP-1800 is a bridge type surface polishing machine with automatic head change, accurate and stable, versatile and efficient, which is a true all rounder for calibration, matt grinding, polishing, brushing and disc blasting all common materials, such as granite, quartz, marble, limestone...
This slab polishing machine can be configurated in different solutions, with 2 different traverse capacities ( 2220 or 3200 mm ), with automatic tool change, with mechanical or motorized stop…etc.
The runway length is adjustable according to your needs and your workshop area.


應用程序

* 軟質石材(大理(li)石、縞(gao)瑪瑙、皂石等(deng))用法蘭克(ke)福頭進行(xing)拋光

* 硬質石(shi)材(cai)(花(hua)崗巖、石(shi)英、石(shi)英巖等)用菲(fei)克特頭進行拋(pao)光

Applications
* Hard stone (granite, quartz, quartzite, etc.) polishing with fickert head
* Soft stone (marble, onyx, soapstone, etc.) polishing with frankfurt head


聯系我們,獲取完整方案!
Contact us to obtain the complete solution!


Hot Tags: hualong 5 axis cnc stone cutting machine, China, manufacturers, suppliers, factory, price, for sale, Granite Tile Polishing Machine, 5 Axis CNC Stone Saw, Double Blade Granite Quarry Machinery, Multi Balde Stone Cutting Machine, Automatic Stone Bridge Saw, CNC Sawjet
華隆機(ji)械,數控(kong)五軸橋(qiao)切機(ji),四軸橋(qiao)切機(ji),4+1橋(qiao)切,5+1橋(qiao)切,三軸橋(qiao)切機(ji),紅(hong)外(wai)線(xian)橋(qiao)切機(ji),石(shi)材切機(ji),石(shi)材加工廠設備,石(shi)材拋光(guang)機(ji),石(shi)材拋光(guang)設備,石(shi)材加工中心(xin),臺面加工中心(xin),水刀,水刀切割機(ji),礦(kuang)山(shan)開采設備,礦(kuang)山(shan)圓盤鋸(ju),圓盤雙(shuang)刀鋸(ju),礦(kuang)山(shan)機(ji),礦(kuang)山(shan)鋸(ju)。

產品型號 Name 單位 HLDM-1800
主電機功率 Power of main motor kw 11
工作平臺尺寸 Working platform dimensions mm 3200 x 2000
需要氣壓 Air pressure required Mpa 0.3 - 0.5
最大加工尺寸 Max. processing dimensions mm 3200 x 3200 x 60
工作臺傾斜 Working platform tilting degree 0-85
拋光頭轉速 R.P.M. of polishing head r/min 550
X軸進給速度 X axis feeding speed mm/min 5300
Y軸進給速度 Y axis feeding speed  mm/min 4000
耗氣量 Air consumption m3/min 0.15 - 0.3
耗水量 Water consumption m3/h 4
總重量 Gross weight kg 7000
機臺尺寸 Dimension (L x W x H) mm 6000 x 5000 x 2800

溫馨提示:如果想了解更多細(xi)節(jie),規格、標準(zhun)、價格和解決方案,請聯(lian)系我(wo)們(men)。
